Telescopic Universal Joint	LMAX = Length Max LMIN = Length Min B1 = Bore 1 B2 = Bore 2 OD = Outside Diameter SSD = Set Screw Diameter SD = Small Diameter LD = Large Diameter JL = Joint Length ES = End to Spider
Material: Aluminum-stainless steel, black anodized. .0005"/in. of travel, .0001" Positional repeatability, Load capacity: 20 lb. horizontal, 5 lb. vertical

LMAX = Length Max
LMIN = Length Min
B1 = Bore 1
B2 = Bore 2
OD = Outside Diameter
SSD = Set Screw Diameter
SD = Small Diameter
LD = Large Diameter
JL = Joint Length
ES = End to Spider

Part		Length Max	Length Min	Bore 1	Bore 2	Outside Diameter	Set Screw Diameter	Small Diameter	Large Diameter	Joint Length	End to Spider
Buy	View
	CMX-A1-1	5.297	4.078	.1250	.1250	.38	.43	.125	.156	1.297	.734
	CMX-A1-2	5.297	4.078	.1250	.1875	.38	.43	.125	.156	1.297	.734
	CMX-A1-3	5.297	4.078	.1875	.1875	.38	.43	.125	.156	1.297	.734
	CMX-A1-4	7.344	5.484	.1875	.1875	.50	.56	.188	.219	1.610	.906
	CMX-A1-5	7.344	5.484	.1875	.2500	.50	.56	.188	.219	1.610	.906
	CMX-A1-6	7.344	5.484	.2500	.2500	.50	.56	.188	.219	1.610	.906
	CMX-A1-7	10.219	7.719	.2500	.2500	.63	.68	.250	.313	2.375	1.328
	CMX-A1-8	10.219	7.719	.2500	.3125	.63	.68	.250	.313	2.375	1.328
	CMX-A1-9	10.219	7.719	.2500	.3750	.63	.68	.250	.313	2.375	1.328
	CMX-A1-10	10.219	7.719	.3125	.3125	.63	.68	.250	.313	2.375	1.328
	CMX-A1-11	10.219	7.719	.3125	.3750	.63	.68	.250	.313	2.375	1.328
	CMX-A1-12	10.219	7.719	.3750	.3750	.63	.68	.250	.313	2.375	1.328
